6 8 10 12 nti dav hlau xuas tshuab foob
Cov Lus Qhia Ceev
Qhov hnyav: 20ton （min）
Ntawv pov thawj: ISO9001: 2008
Warranty: 1 Xyoo
Kev pab cuam tom qab muag Tau: Khoom seem pub dawb, Kev pab hauv online, kev teeb tsa sab nraud, kev cog lus thiab kev cob qhia, Engineers muaj rau kev pabcuam tshuab txawv teb chaws
Kev Siv: Dredging Av nkev / xuab zeb / tsuas
Kev faib tawm nrug: 1200m
Cov dej ntws tawm: 1800 M3 / teev
Ua hauj lwm muaj peev xwm: 220m3
Xuas kawg txoj kab uas hla: 400mm
Kev tawm ntawm lub qhov taub loj kawg: 300mm
Tag nrho cov hwj huam: 670kw
Lub taub hau txiav taub: 1200mm
6 nti dav hlau nqus dredger ntawm kev tsim kho steel, hom uas tsis yog nws tus kheej, dismountable yog muaj peev xwm mus rau berth thiab dredge ntawm txhua qhov dej nyob ntawm thaj chaw ntug hiav txwv thiab dej tsis muaj dej, muaj cov xwm txheej zoo sib xws rau ntawd hauv thaj chaw navigation" A" lossis hauv qab ntawm"" -line sau hauv qhov code rau" dej hiav txwv steel hlau nkoj tsim khoom ntawm PRChina" ;.
8 ntiv nplhaib dav hlau nqus dredgercan siv los khawb thiab thauj cov cohesive sediment hauv qab chav kawm III tau sau tseg rau hauv txoj cai rau" kev tsim hluav taws xob kev tsim hluav taws xob kev tsim qauv kev cai" muab los ntawm Ministry of Water Resources (MWR) ntawm PRChina.
10 nti Ncaws Hnav dredgerconsists ntawm lub ntsiab pontoon thiab ob sab pontoons. Kev tsim kho ua rau kev cais tawm sai thiab yooj yim rau thauj los ntawm txoj kev, kev tsheb nqaj hlau lossis dej hiav txwv, kuj yooj yim dua los hloov ntawm qhov chaw. Cav thiab dredging twj tso kua mis nyob rau hauv lub pontoon lub ntsiab. Lub pontoons hauv ib sab tuaj yeem raug siv roj roj tank, ballast tank thiab cov tub rog qhuav.
Lub chav tswj dav dav yog ergonomically tsim nrog 360 degree pom. Txhua lub lag luam nyees khawm, hloov khoom siv, ntsuas ntsuas, ntsuas ntsuas yog nruab rau ntawm lub rooj tswj hwm. Tsuas yog ob tus neeg ua haujlwm tuaj yeem tswj tau li 12 nti Dav hlau xuas dej dredgerin chav ua haujlwm.
Plaub txheej anticorrosive marine xim muab cov zinc anode tiv thaiv los txhim kho cov nyhuv ntawm kev txhim kho.
| SPECIFICATIONS RAU Cov Txiav Txiav Dredger | ||||||
Qauv | TJD100 | TJD200 | TJD300 | TJD400 | TJD450 | TJD500 |
Dej ntws (m / h) | 280 | 800 | 1800 | 3000 | 3500 | 5000 |
Ntev (m) | 19 | 26 | 35 | 40 | 41 | 43 |
Dav (m) | 3.5 | 5.3 | 6.6 | 7.5 | 8 | 9.5 |
Qhov siab (m) | 1 | 1.5 | 1.8 | 2.2 | 2.5 | 2.5 |
Max.dredging qhov tob (m) | 8 | 12 | 15 | 15 | 17 | 18 |
Xuas kawg diam (hli) | 150 | 250 | 400 | 500 | 650 | 650 |
Paug kawg diam (hli) | 100 | 200 | 300 | 400 | 450 | 500 |
Tag nrho cov hwj huam (KW) | 132 | 336 | 670 | 1000 | 1166 | 2364 |
Lub taub hau Cutter taub (hli) | 650 | 950 | 1200 | 1500 | 1700 | 2000 |
Kev ncua deb (m) | 400 | 800 | 1200 | 1500 | 1800 | 3000 |
Nta Tseem Ceeb
1) CCS ISO9001: 2008 Daim Ntawv Pov Thawj;
2) Lub tshuab zom khoom siv txiav kub ua si yog ib hom tsis tuaj yeem txiav cov nqus dej txiav thiab tsis tuaj;
3) Lub tshuab txiav tau ncaj qha tsav los ntawm ib lub tshuab hluav taws xob qis qis hydraulic;
4) Ob qhov kev txiav txim siab tau ua haujlwm los ntawm kev ua haujlwm ntawm hydraulic ram;
5) Cov roj rau cov hydraulic siv los ntawm cov twj tso kua mis.
Cov FAQ
1) Kuv tsis tau siv lub tshuab zoo no, nws puas yooj yim rau kev khiav lag luam?
Peb cov engineers yuav taw qhia koj hauv kev teeb tsa thiab siv, thiab muaj cov phau ntawv qhia lus Askiv thiab phau ntawv qhia ua haujlwm uas qhia kev siv tshuab.
2) Kuv yuav ua li cas yog tias lub tshuab muaj teeb meem tom qab kuv xaj nws?
Cov khoom pub dawb xa tuaj rau koj hauv tshuab warranty lub sijhawm yog tias lub tshuab muaj teeb meem.Free tom qab-muag kev pab cuam lub neej rau tshuab, thov xav tiv tauj peb yog tias koj lub tshuab muaj teeb meem. Peb yuav muab cov kev daws teeb meem ntawm koj hauv xov tooj thiab skype.
